Rotary HydraulicCathead
2014-8-19 Browse:4171times
Rotary cathead is widely used to tighten or loosen joint in drilling and service operation. It also is applicable for hauling and lifting weight. The cathead is hydraulically driven and braked. It feathers high start torque, stable running, and low noise, safe and reliable.
Model |
YXM-2 |
YXM-5 |
YXM-13 |
YXM-10/3 |
XM-18/3 |
||||||
Secondary drum |
Main drum |
Secondary drum |
Main drum |
||||||||
Flow rating |
L/min |
40 |
120 |
120 |
120 |
120 |
|||||
gpm |
10.6 |
31.7 |
31.7 |
31.7 |
31.7 |
||||||
Pressure rating |
MPa |
16.6 |
16.6 |
16.6 |
16.6 |
20 |
|||||
psi |
2400 |
2400 |
2400 |
2400 |
2900 |
||||||
Pull rating |
kN |
20 |
50 |
130 |
30 |
100 |
30 |
180 |
|||
US ton |
2.2 |
5.5 |
14.3 |
3.3 |
11 |
3.3 |
19.8 |
||||
Average rope speed |
m/min |
30 |
42 |
14 |
65 |
15 |
54 |
10.8 |
|||
ft/min |
98 |
137 |
46 |
212 |
49 |
176 |
35 |
||||
Wire rope diameter |
mm |
10 |
18 |
24 |
25.4coir rope |
24 |
25 |
25 |
|||
in |
3/8 |
23/32 |
15/16 |
1 |
15/16 |
1 |
1 |
||||
Rope storage |
m |
15 |
50 |
40 |
50 |
40 |
12 |
20single |
|||
ft |
49 |
164 |
131 |
164 |
131 |
39 |
65.5 |
||||
Size |
mm |
580*400*430 |
878*560*600 |
1120*730*750 |
1072*580*618 |
1780*1280*1220 |
|||||
in |
23*16*17 |
34.5*22*23.5 |
44*29*29.5 |
42*23*24 |
70*50*48 |
||||||
Weight |
kg |
160 |
280 |
400 |
800 |
2484 |
|||||
lb |
353 |
617 |
882 |
1764 |
5477 |
||||||
